Inverter Output • Rated Power: 10000W • Surge Power: 30000W • Waveform: Pure Sine Wave / Same As Input(Bypass Mode) • Nominal Output Voltage RMS: 220VAC/230VAC/240VAC ±10% RMS • Output Frequency: 50Hz/60Hz ±0.3Hz • Efficiency: Inverter >88% / Line Mode >95% • Power Factor: 1 • Transfer Time: 10ms Typical, 20ms Max Solar Charger • Maximum PV Charge Current: 120A • Maximum PV Array Power: 7000W • Number of MPP Trackers: 2 • Strings per MPP Tracker: 1 • MPPT Range at Operating Voltage: 60VDC-145VDC • Maximum PV Array Open Circuit Voltage: 150VDC AC Input • AC Input Voltage: 230VAC • Selectable Voltage Range (Home Appliances): 154VAC-272VAC • Selectable Voltage Range (UPS): 184VAC-272VAC • Frequency Range: 50Hz / 60Hz (Auto Sensing) • Maximum Charge Current: 80A Environment Limit • Ingress Protection: IP20 • Operating Temperature Range: 0°C to +45°C • Communication: WIFI/GPRS Get Datasheet here
The KODAK OG 10 is the latest in the range of the KODAK OG products. With 10000W of capacity, it can easily take an average house off of the grid. The KODAK OG 10 Solar inverter comes with a large colored LCD display and built in Wi-Fi for online mobile monitoring. The dual MPPT’s will ensure you get optimal solar production.
Customizable status LED ring with RGB lights
Touchable button with large 5″ colored LCD
Built-in Wi-Fi for mobile monitoring (Android/iOS App is available)
Supports USB On-the-Go function
Reserved communication port for BMS (RS485, CAN-BUS or RS232)
Replaceable fan design for ease of maintenance
Configurable AC/PV output usage timer and prioritization
Selectable high power charging current
Compatible to Utility Mains or generator input
Built-in anti-dust kit
Built-in DC output for DC fan, LED bulb, router and so on.
